Multi V 5
Pentru informatii referitoare la sistemele Multi V, oferte personalizate, participari la licitatii, va rugam sa ne contactati la contact@lgshop.ro
Nomenclator:
ARU M 100 L T E 5
ARU - MULTI V System with Indoor Unit using R410A |
ARU : Global line-up
M - Combination of Inverter Type and Cooling Only,
Heat Pump or Heat Recovery |
M : Inverter, Heat Pump and Heat Recovery
100 - Total Cooling capacity in Horse Power(HP) unit |
EX 8HP → ‘080’, 10HP → ‘100
L - Electrical Ratings |
L : 3Ø, 380 ~ 415 V, 50Hz
T - Air Discharge Type |
T : Top Discharge
E - E: High Efficiency
5 - Serial number
MULTI V 5
ARUM080LTE5 / ARUM100LTE5
ARUM120LTE5 / ARUM140LTE5
| HP | 8 | 10 | 12 | 14 | |
|---|---|---|---|---|---|
| Model | Combination unit | ARUM080LTE5 | ARUM100LTE5 | ARUM120LTE5 | ARUM140LTE5 |
| Independent unit | ARUM080LTE5 | ARUM100LTE5 | ARUM120LTE5 | ARUM140LTE5 | |
ARUM160LTE5 / ARUM180LTE5
ARUM200LTE5 / ARUM220LTE5
| HP | 16 | 18 | 20 | 22 | |
|---|---|---|---|---|---|
| Model | Combination unit | ARUM160LTE5 | ARUM180LTE5 | ARUM200LTE5 | ARUM220LTE5 |
| Independent unit | ARUM160LTE5 | ARUM180LTE5 | ARUM200LTE5 | ARUM220LTE5 | |
ARUM240LTE5 / ARUM260LTE5
ARUM221LTE5 / ARUM241LTE5
| HP | 24 | 26 | 22' | 24' | |
|---|---|---|---|---|---|
| Model | Combination unit | ARUM240LTE5 | ARUM260LTE5 | ARUM221LTE5 | ARUM241LTE5 |
| Independent unit | ARUM240LTE5 | ARUM260LTE5 | ARUM120LTE5 ARUM100LTE5 |
ARUM120LTE5 ARUM120LTE5 |
|
ARUM261LTE5 / ARUM280LTE5
ARUM300LTE5 / ARUM320LTE5
| HP | 26' | 28 | 30 | 32 | |
|---|---|---|---|---|---|
| Model | Combination unit | ARUM261LTE5 | ARUM280LTE5 | ARUM300LTE5 | ARUM241LTE5 |
| Independent unit | ARUM140LTE5 ARUM120LTE5 |
ARUM160LTE5 ARUM120LTE5 |
ARUM180LTE5 ARUM120LTE5 |
ARUM200LTE5 ARUM120LTE5 |
|
ARUM340LTE5 / ARUM360LTE5
ARUM380LTE5 / ARUM400LTE5
| HP | 34 | 36 | 38 | 40 | |
|---|---|---|---|---|---|
| Model | Combination unit | ARUM340LTE5 | ARUM360LTE5 | ARUM380LTE5 | ARUM400LTE5 |
| Independent unit | ARUM220LTE5 ARUM120LTE5 |
ARUM240LTE5 ARUM120LTE5 |
ARUM240LTE5 ARUM140LTE5 |
ARUM240LTE5 ARUM160LTE5 |
|
ARUM420LTE5 / ARUM440LTE5
ARUM460LTE5 / ARUM480LTE5
| HP | 42 | 44 | 46 | 48 | |
|---|---|---|---|---|---|
| Model | Combination unit | ARUM420LTE5 | ARUM440LTE5 | ARUM460LTE5 | ARUM480LTE5 |
| Independent unit | ARUM240LTE5 ARUM180LTE5 |
ARUM240LTE5 ARUM200LTE5 |
ARUM240LTE5 ARUM220LTE5 |
ARUM240LTE5 ARUM240LTE5 |
|
ARUM500LTE5 / ARUM520LTE5
ARUM540LTE5 / ARUM560LTE5
| HP | 50 | 52 | 54 | 56 | |
|---|---|---|---|---|---|
| Model | Combination unit | ARUM500LTE5 | ARUM520LTE5 | ARUM540LTE5 | ARUM560LTE5 |
| Independent unit | ARUM240LTE5 ARUM140LTE5 ARUM120LTE5 |
ARUM240LTE5 ARUM160LTE5 ARUM120LTE5 |
ARUM240LTE5 ARUM180LTE5 ARUM120LTE5 |
ARUM240LTE5 ARUM200LTE5 ARUM120LTE5 |
|
ARUM580LTE5 / ARUM600LTE5
ARUM620LTE5 / ARUM640LTE5
ARUM660LTE5
| HP | 58 | 60 | 62 | 64 | 66 | |
|---|---|---|---|---|---|---|
| Model | Combination unit | ARUM580LTE5 | ARUM600LTE5 | ARUM620LTE5 | ARUM640LTE5 | ARUM660LTE5 |
| Independent unit | ARUM240LTE5 ARUM220LTE5 ARUM120LTE5 |
ARUM240LTE5 ARUM240LTE5 ARUM120LTE5 |
ARUM240LTE5 ARUM240LTE5 ARUM140LTE5 |
ARUM240LTE5 ARUM240LTE5 ARUM160LTE5 |
ARUM240LTE5 ARUM240LTE5 ARUM180LTE5 |
|
ARUM680LTE5 / ARUM700LTE5
ARUM720LTE5 / ARUM740LTE5
ARUM760LTE5
| HP | 68 | 70 | 72 | 74 | 76 | |
|---|---|---|---|---|---|---|
| Model | Combination unit | ARUM680LTE5 | ARUM700LTE5 | ARUM720LTE5 | ARUM740LTE5 | ARUM760LTE5 |
| Independent unit | ARUM240LTE5 ARUM240LTE5 ARUM200LTE5 |
ARUM240LTE5 ARUM240LTE5 ARUM220LTE5 |
ARUM240LTE5 ARUM240LTE5 ARUM240LTE5 |
ARUM240LTE5 ARUM240LTE5 ARUM140LTE5 ARUM120LTE5 |
ARUM240LTE5 ARUM240LTE5 ARUM160LTE5 ARUM120LTE5 |
|
ARUM780LTE5 / ARUM800LTE5
ARUM820LTE5 / ARUM840LTE5
ARUM860LTE5
| HP | 78 | 80 | 82 | 84 | 86 | |
|---|---|---|---|---|---|---|
| Model | Combination unit | ARUM780LTE5 | ARUM800LTE5 | ARUM820LTE5 | ARUM840LTE5 | ARUM860LTE5 |
| Independent unit | ARUM240LTE5 ARUM240LTE5 ARUM180LTE5 ARUM120LTE5 |
ARUM240LTE5 ARUM240LTE5 ARUM200LTE5 ARUM120LTE5 |
ARUM240LTE5 ARUM240LTE5 ARUM220LTE5 ARUM120LTE5 |
ARUM240LTE5 ARUM240LTE5 ARUM240LTE5 ARUM120LTE5 |
ARUM240LTE5 ARUM240LTE5 ARUM240LTE5 ARUM140LTE5 |
|
ARUM880LTE5 / ARUM900LTE5
ARUM920LTE5 / ARUM940LTE5
ARUM960LTE5
| HP | 88 | 90 | 92 | 94 | 96 | |
|---|---|---|---|---|---|---|
| Model | Combination unit | ARUM880LTE5 | ARUM900LTE5 | ARUM920LTE5 | ARUM940LTE5 | ARUM960LTE5 |
| Independent unit | ARUM240LTE5 ARUM240LTE5 ARUM240LTE5 ARUM160LTE5 |
ARUM240LTE5 ARUM240LTE5 ARUM240LTE5 ARUM180LTE5 |
ARUM240LTE5 ARUM240LTE5 ARUM240LTE5 ARUM200LTE5 |
ARUM240LTE5 ARUM240LTE5 ARUM240LTE5 ARUM220LTE5 |
ARUM240LTE5 ARUM240LTE5 ARUM240LTE5 ARUM240LTE5 |
|
